20/54
• Install the camshaft retaining cover. (pay
careful attention to the tightening order).
Camshaft retaining cover torque
10Nm
• Install the camshaft chain tensioner
using a new gasket.
Torque the two fixing bolts to:
10Nm
• Install the cam tensioner adjusting bolt
(pay attention to the o-ring).
Torque the tensioner adjusting screw to:
10Nm
• Remove the special tool number 1819.
• Rotate the engine a few times to make
sure that the valve timing is correct.
• Finally check the valve timing using the
timing marks.
• Replace the cap that was removed to
install tool number 1819.
Torque the cap to:
8Nm
• Replace the spark plug well.
Make sure that the o-rings are installed on
the spark plug well.
