48/54
Cable diagram (Injection / light)
Injection beam
ECU connections :
PIN Fonction
1
5 volts
2 NC
3
RPM (information)
4
Water temperaturel
5
Ventilator
6 NC
7
RPM sensor -
8
NC
9
Diagnostique connector
10 Dignostique connector
11
TPS sensor
12
RPM sensor +
13
Injector
14 NC
15
NC
16
GND for double ignition mapping
17
+V_BATT +12v
18 Water temperature
19
Fuel relay
20
Ignition spark plug
21
NC
22 Sensor GND
23
GND Power
24
NC
25
N C
26 + After Key
