11/54
Motor top end
For additional details refer to the parts catalog SE 250i_SE 300i..
Removing the cylinder head:
Remove the spark plug.
Remove the valve cover.
Remove the three valve cover screws.
These three screws are equipped with o-
rings ref: 0900.
Remove the cap from the ignition cover.
[A].
Remove the timing control plug [A]
Turn the engine counterclockwise in
order to align the timing marks on the
crankshaft with the marks on the timing gear.
Install the special tool that locks the engine at
Top Dead Center [A] (ref 1819)
A
A
A
