SHERCO 2013 SE 250i-R User Manual

12/54
• Remove the screws from the cam chain
tensioner as shown in the photo.
• Remove the cam chain tensioner.
• Remove the spark plug well.
• Remove the camshaft bearing journal.
Starting on the inside, remove the screws
In a criss cross manner (see the numbers on
the photo).
• Remove the exhaust camshaft retaining
clip.
• Remove the exhaust camshaft.
• Remove the intake camshaft retaining
clip.
• Remove the intake camshaft.
• Remove the two nuts M6 and the
washer.
1
2
3
1
2
3
4 5
7
6
