36/54
Tightening torques
Standard torque
Threadlocker
M5 6 Nm
M6 10 Nm
M8 24 Nm
M10 40 Nm
Frame tightening torques Threadlocker
Rear wheel axle nut 100 Nm
Aluminium sub frame bolts 24 Nm •
Front wheel axle nut 40 Nm
Front fork /axle bolts / axle M6 15 Nm
Brake pad bolt 8 Nm •
Botton plat fork bolts
Wp 12 Nm
Sachs 15 Nm
Upper plat fork bolts
Wp 17 Nm
Sachs 17 Nm
Motor screw 60 Nm
Swing arm nut 100 Nm
Cylinder head-frame srews 23 Nm
Motor tightening torques Threadlocker
Magnetic drain plug 22 Nm
Drain plug with prefilter 22 Nm
Oil filter cover 15 Nm
Spark plug (with copper grease) 15 Nm
Bolt for bleeding cooling system 6 Nm
