Motor tightening torques Threadlocker
Ignition sensor screw 8 Nm •
Bolt for bleeding cooling system 6 Nm
Clutch slave cylinder screw 9 Nm
Exhaust bolt 10Nm
Cylinder head
1
st
pass
2nd pass
Hexagon nut M6
30 Nm
50 Nm
10 Nm
Camshaft cap 10 Nm
Chain tensioner screw (x2) 10 Nm
Chain tensioner screw (x1) 10 Nm
Timing control plug 8 Nm
Chain guide screw 10 Nm •
Clutch pression screw 10 Nm
Water pump cover 11 Nm
Rotor nut 100 Nm •
Clutch nut 80 Nm •
Oil breather wheel 8 Nm
Ignition cover 10 Nm
Crankcase screw 10 Nm
Gear selector drum screw 10 Nm
Oil pump cover 5 Nm
Balancer nut 60 Nm •
