46/54
Value of the butterfly angle position should be: 2.7 <3.1 <3.5
Check that the painting has not accidentally removed from the butterfly stop screw. Never touch
the butterfly stop screw.
The bike must be in perfect working condition (valves adjusted properly, fresh air filter, etc.).
Check that air by-pass air screw at the injector body is not unscrewed over two TURNS out
(factory value: 1 round).
Make this adjustment with the engine running.
1- For this operation you must have a lambda probe and a gas analyzer.
- Run the engine until it reaches 80 ° C.
- Connect the CO detector
- Perform the test in real conditions (saddle and air filter installed)
- In the Configuration menu, set the CO at 5%
Do not exceed the range of -15 to +15. If you must get out of this range, there is a
problem (injector, TPS sensor, etc.).
2 – If you do not have a lambda probe and gas analyzer.
If your perfectly tuned bike has an unstable idle you can set it using the Trimmer function.
Do not exceed the range of -15 to +15. If you must get out of this range, there is a
problem (injector, TPS sensor, etc.).
Idle speed : 2.5i : 2200 +/-100tr/min
