62
Introduction of Shihlin Inverter
Introduction of Inverter
3.6.2 Power cable specification/pressing connection terminals specification
Power Cable Specification
(PVC cables standard)
Pressing connection terminal
specification (used by powe cables)
Power supply terminal
(R/L1- S/L2- T/L3)
Loading terminal
(U/T1-V/T2-W/T3)
Inverter Type
Crimping
terminal
(mm
2
)
Tightening
torque
(Kgf.cm)
Crimping
terminal
(mm
2
)
Tightening
torque
(Kgf.cm)
Power supply
terminal
Loading
terminal
SS2-021-0.4K 2.5 12.2 2.5 12.2 2-3.5 2-3.5
SS2-021-0.75K 2.5 12.2 2.5 12.2 2-3.5 2-3.5
SS2-021-1.5K 2.5 18 2.5 18 2-4 2-4
SS2-021-2.2K 4 18 4 18 5.5-4 2-4
SS2-023-0.4K 2.5 12.2 2.5 12.2 2-3.5 2-3.5
SS2-023-0.75K 2.5 12.2 2.5 12.2 2-3.5 2-3.5
SS2-023-1.5K 2.5 12.2 2.5 12.2 2-3.5 2-3.5
SS2-023-2.2K 4 18 2.5 18 3.5-4 2-4
SS2-023-3.7K 4 18 4 18 5.5-4 5.5-4
SS2-043-0.4K 2.5 12.2 2.5 12.2 2-3.5 2-3.5
SS2-043-0.75K 2.5 12.2 2.5 12.2 2-3.5 2-3.5
SS2-043-1.5K 2.5 12.2 2.5 12.2 2-3.5 2-3.5
SS2-043-2.2K 2.5 18 2.5 18 2-4 2-4
SS2-043-3.7K 2.5 18 2.5 18 2-4 2-4
SS2-043-5.5K 4 18 2.5 18 5.5-4 2-4
