27
Introduction of Shihlin Inverter
Introduction of Inverter
3.6.3 Brake resistors
Inverter Type Brake Resistor Specification Inverter Type Brake Resistor Specification
SS2-021-0.4K 100W 220ȍ SS2-023-3.7K 400W 40ȍ
SS2-021-0.75K 150W 120ȍ SS2-043-0.4K 80W 1000ȍ
SS2-021-1.5K 300W 60ȍ SS2-043-0.75K 100W 800ȍ
SS2-021-2.2K 300W 60ȍ SS2-043-1.5K 200W 320ȍ
SS2-023-0.4K 100W 220ȍ SS2-043-2.2K 300W 160ȍ
SS2-023-0.75K 150W 120ȍ SS2-043-3.7K 500W 120ȍ
SS2-023-1.5K 300W 60ȍ SS2-043-5.5K 1000W 75ȍ
SS2-023-2.2K 300W 60ȍ
Note: 1. The brake resistor capacity listed in the above table is based on a 10% regenerative brake duty (that is, in
case braking lasts for 5 seconds, another 45 seconds must be provided for heat dissipation). The brake
resistor wattage can be reduced according to the user’s application (quantity of heat) and the regenerative
brake duty. But the resistance must be larger than the value list in the above table (otherwise damage of
the inverter thus be resulted in).
2. In case frequent start and stop operations are required, a larger regenerative brake duty should be set;
meanwhile, a larger brake resistor should be employed correspondingly. If there is any problem about
selection of brake resistors, please feel free to contact us.
3.6.4 EMI filter
Inverter Type Schaffner Filter Type Inverter Type Schaffner Filter Type
SS2-021-0.4K SS2-043-0.4K
SS2-021-0.75K
NF211B10/01
SS2-043-0.75K
SS2-021-1.5K NF241B20/05 SS2-043-1.5K
NF311A10/01
SS2-021-2.2K NF241B30/25 SS2-043-2.2K
SS2-023-0.4K SS2-043-3.7K
SS2-023-0.75K SS2-043-5.5K
NF311A20/05
SS2-023-1.5K
NF311A10/01
SS2-023-2.2K
SS2-023-3.7K
NF311A20/05
Note: Products of CHANGZHOU DUOJI EME TECHNICAL CO., LTD are recommended for the filter used
here.
