3.6.5 Zero-phase reactor
Motor Capacity
Inverter Type
HP kW
Qty.
Recommended Wire
Size (mm
2
)
Wiring Method
1/2 0.4
1 0.75
1
2 1.5
0.5-5.5
220V
Single- phase
3 2.2
2
3.5-5.5
Diagram A
1/2 0.4
1 0.75
2 1.5
1 0.5-5.5
5.5-5.3 2.2 3
220V
Three- phase
5 3.7
2
5.5
Diagram A
1/2 0.4
1 0.75
2 1.5
1
3 2.2
5 3.7
0.5-5.5
440V
Three-phase
7.5 5.5
2
3.5-5.5
Diagram A
Diagram A: Please wind each four times around the core and around the same.
UNIT:mm
P41T63*38*25C
63
38
25
