29
Introduction of Shihlin Inverter
Introduction of Inverter
3.6.6 Input/output reactor
Input AC Line Reactor
220Vˈ50/60HzˈThree-phase
kW
Rated Amps of
Inverter
2% Impedance Reactor Types 4% Impedance Reactor Types
0.4 3 ACL-0005-EISC-E3M8 ACL-0005-EISC-E5M6
0.75 5 ACL-0005-EISC-E3M8 ACL-0005-EISC-E5M6
1.5 8 ACL-0010-EISC-E1M5 ACL-0010-EISC-E2M8
2.2 11 ACL-0015-EISC-E1M0 ACL-0015-EISC-E1M9
3.7 17.5 ACL-0020-EISC-EM75 ACL-0020-EISC-E1M4
440Vˈ50/60HzˈThree-phase
kW
Rated Amps of
Inverter
2% Impedance Reactor Types 4% Impedance Reactor Types
0.4 1.5 ACL-0005-EISC-E3M8 ACL-0005-EISC-E5M6
0.75 2.6 ACL-0005-EISC-E3M8 ACL-0005-EISC- E5M6
1.5 4.2 ACL-0005-EISC-E3M8 ACL-0005-EISC- E5M6
2.2 6 ACL-0007-EISC-E2M5 ACL-0007-EISC-E3M5
3.7 9 ACL-0010-EISC-E1M5 ACL-0010-EISC-E2M8
5.5 12 ACL-0015-EISC-E1M0 ACL-0015-EISC-E1M9
Output AC Line Reactor
220Vˈ50/60HzˈSingle-phase
kW
Rated Amps of
Inverter
1% Impedance Reactor Types 2% Impedance Reactor Types
0.4 2.7 OCL-0005-EISC-E1M4 OCL-0005-EISC-E2M8
0.75 4.5 OCL-0005-EISC-E1M4 OCL-0005-EISC-E2M8
1.5 8 OCL-0010-EISC-EM70 OCL-0010-EISC- E1M4
2.2 11 OCL -0015-EISC-EM47 OCL -0015-EISC-EM93
