Parameter Description
Parameter Description
<Setting>
• If P.14=4, P.19=220V, P.98=5Hz and P.99=10%, the output voltage equals to P.99 P.19=10%
220V=22V when the inverter is run at 5Hz.
• P.46
Second Torque Boost is valid if RT is on.
P.14
0
Applicable to constant torque loads
(conveyer belt, etc.)
P.14 1
Applicable to variable torque loads
(fans, pumps, etc.)
P.14 2
Ascending/descending loads
P.14 3
Ascending/descending loads
P.14 4
A high startup torque or descending torque is
due to the set values
Note 1 .
P.14=5
A is 7.1% when P.14=5.
Output frequency
P.0
0 P.3
Output voltage
P.19
P.0
0 P.3
P.19
Output voltage
Output frequency
P.0
0 P.3
P.19
F
orwar
d
r
ot
a
ti
ng
R
ever
s
e
l
y
r
o
t
a
t
in
g
Output voltage
Output frequency
P.0
0 P.3
P.19
F
orwar
d
r
o
t
at
i
n
g
R
eversely
r
o
tati
n
g
Output voltage
Output frequency
0
P.0
P.98 P.162 P.164 P.166
P.168
P.99
P.169
P.167
P.165
P.163
P.19
P.3
Output voltage
（%）
Output frequency (Hz)
Output frequency
P.0
0 P.3
Output voltage
P. 19
A
P.98=3.0
0.1
To Next Page
