5 Maintenance and Inspections
5.5 Replacing Photomultiplier
69FPD-2010
8. Please install the FPD upper cover according to an opposite procedure after the end of work.
At this time, please install the FPD upper cover for the arrow to press photomultiplier against the main
body pushing in the direction.
photomultiplier
Tighten a screw
FPD upper cover
Fig. 5.5.8
