Shimax MAC6A User Manual

5
3-2. Order code table
Item
Code
Specifications
Series
MAP6A-
96 x 96 size 5 digit display programmable digital controller
Series
MAC6A-
96 x 96 size 5 digit display digital controller
Input
M
Full multi TC, RTD, mV, V, mA ※1
Control Output 1
C
Contact 1a 240V AC 2A (Resistance load)
S
Voltage pulse (SSR Drive Voltage) 12V DC max20mA
I
Current 4-20mA DC Load resistance max500Ω
V
Voltage 0-10V DC Load current max2mA
Y
Control motor (Servo control Output)Contact 1C 240V AC 2A
※2
X
Control motor (Servo control Output)SSR 240V AC 2A
Power supply
F-
90-264V AC 50/60Hz
Event Output
E
Even Output 3 points (EV1-3) Contact 1a 240V AC 1A (Resistance load)
Control Output 2
N-
None
C-
Contact 1a 240V AC 2A(Resistance Load)
※2
S-
Voltage pulse 12V DC max20mA
I-
Current 4-20mA DC max500Ω
V-
Voltage 0-10V DC max2mA
Event Output
E-
Event output 1point (EV4) 240V AC 2A
(Resistance load)
DI (External operation input)
D
7 Points (DI1-7) 5V DC 0.5mA
DO-Ⅰ(External operation output Ⅰ)
N
None
J
3 Points(DO1-3) 24V DC 20mA
DO-Ⅱ(External operation output Ⅱ)
CT(Current sensor input)
FB(Feedback input)
N
None
J
DO-Ⅱ 3 Points (DO4-6) 24V DC 20mA
H
CT 2 Points 50.0A
P
FB potentiometer input 3 wire 100Ω～2kΩ
AI(External analogue input)
N
None
I
Current 4-20mA DC
(Reception resistance100Ω)
V
Voltage 0-10V DC
(Input resistance about 500kΩ)
AO(External analogue output)
N
None
T
Current 4-20mA DC
Load resistance max300Ω
V
Voltage 0-10V DC max2mA
Communication
N
None
R
RS-485
W
RS-232C
1 When using by current input, shunt resistance of option parts or same as items (less than 0.05% of 100 Ω ) is needed.
2 When Motor control Y or X installed, Out2 and EV4 cannot install.
