Shimax MAC6A User Manual

77
6-6-11. Mode11 CT setting
Not displayed when CT function is not installed
CT1 mode setting screen
Initial value :
Setting range : 、 、 、 、 、 、
Object detected by CT (current) sensor is chosen.
In the case of a current or voltage pulse output, is not displayed.
is not displayed without current output or output 2 option.
CT1 delay time setting screen
Initial value : 0.5
Setting range : 0.1～1000.0 sec
When control loop abnormal alarm is allotted to event, delay time from switchover of
operation (ON-OFF) to detection start is set up.
CT2 mode setting screen
Same as CT1 mode setting screen
