Latching release setting screen
Initial value:
Setting range: 、
When latching is set as , once DO is output, even if DO is OFF state event output
state is held. Not displayed when DO 1 mode is .
Being initialized if measuring range, scaling, and unit are changed.
DO character setting screen
Initial value:
Setting range: 、
: normal open
: normal close
Not displayed when DO 1 mode is .
Note: If is chosen, relay turns to ON about 1.5 seconds later when power source is
switched on, and turns to OFF in DO output range.
DO Output rating ：Open collector Darlington output ２４ＶＤＣ（Max load ２０ｍＡ）、ＯＮ
saturated voltage１．２Ｖ
