Shinkawa VM-7 Series User Manual

VM-7 System Manual Preface 
1
Thank you very much for purchasing the VM-7 Series Monitor.
<Regarding the Manuals for the VM-7 Series Monitor>
The VM-7 Series Monitor (hereafter “the unit”) comes with four manuals which contain information
for different operations as well as tasks.
This "MCL View Operation Manual" is one of the four.
Manual name System Manual
Intended Users of the Manual Operators who are in charge of the maintenance of the unit
and who confirm the screen in their work
Contents
y
Description of the Unit
y
Specifications and outer size
y
Regular inspection
y
Troubleshooting
Manual name Installation Manual
Intended Users of the Manual Personnel who perform the unit installation into the instrument
panel and required wiring.
Contents
y
Description of unpacking and accessories
y
How to install the unit into the instrument panel
y
How to connect the unit
Manual name MCL View Operation Manual
Intended Users of the Manual Operators who are in charge of the maintenance of the unit and
who confirm the screen in their work.
Contents
y
Overview of the MCL View
y
Description of the screen
y
Operation through the MCL View
Manual name Service Manual
Intended Users of the Manual Personnel who perform the detail settings and maintenance of
the unit
The use of this manual is restricted to those who have completed
the maintenance training course run by our company.
Contents
y
Description of Field Configuration
y
Description of adjustments and calibration
y
Solutions to problems

Shinkawa VM-7 Series Specifications

General

Brand	Shinkawa
Model	VM-7 Series
Category	Measuring Instruments
Language	English
