Shinkawa VM-7 Series User Manual

VM-701 VIBRATION / DISPLACEMENT
MONITOR MODULE
Page 2 of 4
VM-7 SERIES
SPECIFICATIONS
30901E1.3
Issued Feb. 2009
Revised Jun. 2010
A
CCESSORY SPECIFICATION CODE / IDENTIFIED BY TB□
Code Accessory Quantity (Part Code)
/TB1 Transducer input terminal plug (15-pin)
FRONT-MC-1.5/15-STF-3.81(Phoenix Contact) : 2pieces (7072NAB)
Note2)
Recorderr output terminal plug (6-pin)
FRONT-MC-1.5/6-STF-3.81(Phoenix Contact) : 2pieces (7072NAC)
Note2)
Contact output terminal plug (18-pin)
FRONT-MC-1.5/18-STF-3.81 (Phoenix Contact) : 1piece (7072NAA)
/TB2 Contact output terminal plug (18-pin)
FRONT-MC-1.5/18-STF-3.81 (Phoenix Contact) : 1piece (7072NAA)
Note1) D-sub plugs and hoods are not included in this code. Please make
necessary arrangement seperately, if required.
Note2) When individually ordering specify the parts code,it is require to arrange
for a necessary amount.
Specification
ENVIRONMENTAL CONDITION
Operating temperature : 0 to +65°C
Storage temperature : -30 to +85°C
Relative humidity : 20 to 95%RH (noncondensing)
POWER CONSUMPTION
Module : Less than 15W
MATERIAL AND FINISH
Face plate : ABS (Black)
Sheet : Polyester tough top (Gray)
Base plate : Alminium alloy (Silver)
MASS
Body : Max. 1.0kg (2.2lb)
Alarm contact operation
Monitor power ON
Monitor alarm relay mode Monitor power OFF
Normal state Alarm state
NO contact (NORMALLY DE-ENERGIZED) OPEN OPEN CLOSE
NO contact (NORMALLY ENERGIZED) OPEN
CLOSE
OPEN
NC contact (NORMALLY DE-ENERGIZED) CLOSE
CLOSE
OPEN
NC contact (NORMALLY ENERGIZED) CLOSE
OPEN
CLOSE
Default value
INPUT
Monitoring : Displacement input vibration monitor
Monitor range : 0 to 100 µm pk-pk
Input transducer : FK-202F (non-intrinsic safety)
Input points : 4 points
Input impedance : 50kΩ
FILTERING
Low cut-off frequency : 5Hz (4
th
-order)
High cut-off frequency : 4kHz
RECORDER OUTPUT
Output range : 4 to 20mA
(4mA at the burnout)
A
larm
DANGER set point : 80µm
ALERT set point : 60µm
OK set point : -1.4V (Low), -18.8V (High)
Alarm delay time : 3sec (DANGER, ALERT)
Alarm reset : AUTO-RESET
CONTACT OUTPUT
Contact (RELAY1) : OR logic (DANGER-1 / DANGER-2)
Contact (RELAY2) : OR logic (ALERT-1 / ALERT-2)
Contact (RELAY3) : OR logic (NOT-OK-1 / NOT-OK-2)
Contact (RELAY4) : OR logic (DANGER-3 / DANGER-4)
Contact (RELAY5) : OR logic (ALERT-3 / ALERT-4)
Contact (RELAY6) : OR logic (NOT-OK-3 / NOT-OK-4)
Contact Mode : Nomally de-energized
OTHERS
Sequnce set value : 1
Suppression set value : 0%
Fast out : OFF
Timed OK channel defeat : ON
Burnout : Downscale 0%
