Shinkawa VM-7 Series User Manual

I/O type Non-incendive *
1
Tropical spec.
1 European I/O Terminal Type 1 Class I Division 2 CSA
2 D-sub I/O Connector Type
*1 In future
VM-76 INSTRUMENT RACK
Page 1 of 2
VM-7 SERIES
SPECIFICATIONS
MONITOR OUTPUT CONNECTOR for PHASE MARKER
Type and number : 9pin D-sub (female) × 10pieces
Fastener size : #4-40UNC
Matching plug : XM2A-0901 (OMRON)
Matching hood : XM2S-0913 (OMRON)
LOCAL COMMUNICATION CONNECTOR
Type and number : RJ-45 × 1piece
Connected network : 10 Base-T
NETWORK COMMUNICATION CONNECTOR
Type and number : RJ-45 × 2pieces
Connected network : 10 Base-T
ANALYSIS MODULE COMMUNICATION CONNECTOR
Type and number : RJ-45 × 1piece
Connected network : 100Base-T
POWER SUPPLY MODULE TERMINAL BLOCK
Primary for power supply : 1piece
Secondary for power supply : 1piece
OTHERS
Note) The terminal block of each terminals is accessories for each
monitor modules. (see each spec sheets)
As for the rest, it is sold separately.
TRANSDUCER INPUT TERMINAL BLOCK
Type and number : 15pin × 2 block × 10sets
Matching plug : FRONT-MC1.5/15-STF-3.81(PHOENIX CONTACT)
RECORDER OUTPUT TERMINAL BLOCK
Type and number : 6pin × 2 Block × 10sets
Matching plug : FRONT-MC1.5/6-STF-3.81 (PHOENIX CONTACT)
CONTACT OUTPUT TERMINAL BLOCK
Type and number : 18pin × 10pieces
Matching plug : FRONT-MC1.5/18-STF-3.81 (PHOENIX CONTACT)
18 CHANNEL RELAY MODULE OUTPUT TERMINAL BLOCK
Type and number : 18pin × 2pieces
Matching plug : FRONT-MC1.5/18-STF-3.81 (PHOENIX CONTACT)
PHASE MARKER INPUT TERMINAL BLOCK
Type and number : 15pin × 1piece
Matching plug : FRONT-MC1.5/15-STF-3.81 (PHOENIX CONTACT)
CONTACT INPUT TERMINAL BLOCK
Type and number : 6pin × 1piece
Matching plug : FRONT-MC1.5/6-STF-3.81 (PHOENIX CONTACT)
SYSTEM-OK OUTPUT TERMINAL BLOCK
Type and number : 6pin × 1piece
Matching plug : FRONT-MC1.5/6-STF-3.81 (PHOENIX CONTACT)
MONITOR OUTPUT CONNECTOR
Type and number : 9pin D-sub (female) × 10pieces
Fastener size : #4-40UNC
Matching plug : XM2A-0901 (OMRON)
Matching hood : XM2S-0913 (OMRON)
VM-761 Terminal Block / Connector Specification
Model Code / Additional Spec. Code ( )
No entry if additional
spec, codeis not specified.
VM-76 /NB1/TRP
30912E1.1
Issued Feb. 2009
Revised Jun. 2010
