Shinkawa VM-7 Series User Manual

VM-703 TACHOMETER & ECCENTRICITY
MONITOR MODULE
Page 3 of 5
VM-7 SERIES
SPECIFICATIONS
30903E1.2
Issued Feb. 2009
Revised Mar. 2010
INPUT (Tachometer)
Monitoring : Tachometer
Monitor range : 0 to 5000rpm
Input sensor : FK-202F (non-intrinsic safety)
Input points : 2 points
Input impedance : 50kΩ
Input pulsepoints : 60 pulse/rev
Input speed / indicated speed changed ratio
: 1
INPUT (Eccentricity P-P)
Monitor range : 0 to 100µm
Input sensor : FK-202F (non-intrinsic safety)
Input impedance : 50kΩ
Measure range : 1 to 600rpm
Phase marker : 1ch (this module)
INPUT (Eccentricity Direct)
Monitor range : -50 to +50µm
Polarity : Direct
WAVE SHAPE (Tachometer)
Trigger mode : AUTO
Hysterics set value : 1V
PULSEOUTPUT (Tachometer)
Output channel : 1ch
SPEED RELAY SET (Tachometer)
HH set point : 3600rpm (Over speed)
H set point : 3000rpm (Over speed)
L set point : 10rpm (Under speed)
LL set point : 10rpm (Under speed)
Speed relay hysterics : 10rpm
Reset : AUTO-RESET
OK ALARM (Tachometer)
OK set point : -1.4V (Low)
Reset : AUTO-RESET
OK ALARM (Eccentricity)
OK set point : -1.4V (Low), -18.8V (High)
Reset : AUTO-RESET
ALARM (Eccentricity P-P)
DANGER set point : 80µm
ALERT set point : 60µm
Alarm delay time : 3sec (DANGER, ALERT)
Alarm reset : AUTO-RESET
ALARM (Eccentricity Direct)
Set point : Not used
RECODER OUTPUT
Output range : 4 to 20mA
(4mA at the burnout)
CONTACT
Contact (RELAY1) : HH-1(tachometer)
Contact (RELAY2) : H-1 (tachometer)
Contact (RELAY3) : L-1 (tachometer)
Contact (RELAY4) : LL-1 (tachometer)
Contact (RELAY5) : DANGER-3 (Eccentricity P-P)
Contact (RELAY6) : ALERT-3 (Eccentricity P-P)
Contact mode : Normaly de-energized
OTHERS
Suppression set value : 0% (Only eccentricity P-P)
Fast out : OFF
Timed OK channel defeat : ON
Burnout : Downscale 0%
Monitor power ON
Monitor alarm relay mode Monitor power OFF
Normal state Alarm state
NO contact (NORMALLY DE-ENERGIZED) OPEN OPEN CLOSE
NO contact (NORMALLY ENERGIZED) OPEN CLOSE OPEN
NC contact (NORMALLY DE-ENERGIZED) CLOSE CLOSE OPEN
NC contact (NORMALLY ENERGIZED) CLOSE OPEN CLOSE
Default Value
Alarm Contact Operation
