Vacuum hold-down systems
A well-built vacuum system is ideal for repeve cung of plywood and other sheet materials.
ShopBot oers several kits for full-table vacuum systems on our gantry tools.
Holding parts within the material
Tabs
Large parts may shi as they are cut free, leading to a small gouge or notch along the edge. Smaller
parts can be destroyed or even thrown across the room by the cuer.
There are two ways to handle this from within the soware. The rst opon is to create tabs, or leo-
ver “bridges” of material between the part and its surrounding area. Most CAM programs will have an
automated feature for this. The feature for VCarve Pro is shown here.
Adding tabs in VCarve Pro Example of tabs on a part
