Shure Incorporated
33/55
•
•
•
•
Display Automix Gating
Indicates a channel is off (audio signal has dropped below the gate threshold). When en-
abled, the lighting style automatically switches to segment mode.
Off: LED light ring turns off when a channel gates off
Follow mute color:LED light ring switches to assigned mute color when a channel gates off
Unmute Behavior LED activity when the microphone is active
Unmute Color LED color when the microphone is active
Mute Behavior LED activity when the microphone is muted
Mute Color LED color when the microphone is muted
Parametric Equalizer (PEQ)
Maximize audio quality by adjusting the frequency response with the parametric equalizer.
Common equalizer applications:
Improve speech intelligibility
Reduce noise from HVAC systems or video projectors
Reduce room irregularities
Adjust frequency response for reinforcement systems
To turn off all EQ filters, select Bypass all EQ.
If you’re using Shure Designer software to configure your system, please check the Designer help section for more about this topic.
Setting Filter Parameters
Adjust filter settings by manipulating the icons in the frequency response graph, or by entering numeric values. Disable a filter
using the check-box next to the filter.
Filter Type
Only the first and last band have selectable filter types.
Parametric: Attenuates or boosts the signal within a customizable frequency range
Low Cut: Rolls off the audio signal below the selected frequency
Low Shelf: Attenuates or boosts the audio signal below the selected frequency
High Cut: Rolls off the audio signal above the selected frequency
High Shelf: Attenuates or boosts the audio signal above the selected frequency
Frequency
Select the center frequency of the filter to cut/boost
Gain
Adjusts the level for a specific filter (+/- 30 dB)
Q
