Specifications
General
All specifications measured from cardioid polar pattern. Values for all patterns are within ± 3 dB of these specifications unless otherwise noted.
Polar Pattern
All channels independently adjustable
Cardioid, Hypercardioid, Supercardioid, Toroid, Omnidirectional, Bidirectional
Connector Type
RJ45
Power Requirements
Power over Ethernet (PoE), Class 0
Power Consumption
4W, maximum
Weight
362 g (0.8 lbs)
Dimensions
H x W x D
3.6 x 13.4 x 13.4 cm (1.4 x 5.3 x 5.3 in.)
control application
HTML5 Browser-based
Operating Temperature Range
−6.7°C (20°F) to 40°C (104°F)
Storage Temperature Range
−29°C (-20°F) to 74°C (165°F)
Audio
Frequency Response
100 to 20,000 Hz
AES67 or Dante Digital Output
Channel Count 5 total channels (4 independent transmit channels, 1 Automatic mixing transmit channel)
Sampling Rate 48 kHz
Bit Depth 24
Sensitivity
at 1 kHz, , -15 dB Gain Setting
-21 dBFS/Pa
