Chapter 4 Operating Instructions
Ranger E/D
26 SICK IVP • Industrial Sensors • www.sickivp.com • All rights reserved 8011731
Hardware Description
4.4 Dimensional Drawing
Figure 4.3 – Ranger E and D (not to scale)
Fastening threads
(M3 x 3 mm depth)
Fastening threads
(M5 x 9 mm depth)
50 19.5
7.5
25 52
13.5
Fastening threads
(M3 x 3 mm depth)
124.8
16.7
13.2
20
52
Botto
m
S
id
e
