BAR CODE SCANNERS CLV69x
Cloning plugs
CLV69x cloning plug inputs and outputs
Brief description Part no.
Sensor (Sensor 1) IN0 (Sensor 2) IN1 (Sensor 3) IN2 (Sensor 4) IN3 (Sensor 5) IN4 (Sensor 6) Result1 Result2 Result3 Result4 AUX HOST CAN1 CAN2 Eth
D-Sub clone plug (with CDM490 connection module) 2062450
O O O O O O O O O O O O O O
–
I/O clone plug
1)
(with CDM420-0006 connection module) 2062452
O O
– – – –
O O O O O O O
–
O
CAN IN/OUT clone plug 2062453 – – –
O
– – – – – –
O
–
O
– –
CAN redundant clone plug 2062454 – – –
O
– – – – – –
O O O
–
1)
No heating.
Assignment of connection to cloning plug
Brief description Part no.
D-sub clone plug I/O Ethernet clone plug CAN IN/OUT clone plug CAN redundant clone plug
CDB650, connection module for a sensor 1064114 –
O
– –
CDM490, modular connection module for a sensor 1025363
O
– – –
CDM420-0006, modular connection modules for a CLV69x/RFU63x/LECTOR
®
65x 1058634 –
O
– –
CDM420-0007, modular connection modules for two CLV69x/RFU63x/LECTOR
®
65x 1060324 –
O
– –
CDM420-0108, Kit: modular connection module for one sensor, 2 A fuse, Host and AUX inter-
face available on face plate, power supply CMP490, US power cord
1064248 –
O
– –
- For additional accessories, please see page 66
