Technical Information Chapter 3
CLV61x
Mounting
8015592/ZNI9/2017-06-13 © SICK AG · Germany · All rights reserved · Subject to change without notice 15
3.2.4 Dimensional Drawing of the Bracket with Rod Clamp No. 2042802
s
Ø
5. 4
R 10
5.4
53.5
Ø
32
Included to fix the bar code scanner to the bracket:
2 x cylinder head screws M5 x 8, with hexagan socket (AF3), self-locking
Mounting sample
All length measures in mm
Bracket can be
swivelled and fixed
freely on the rod
clamp
(rod not included in delivery)
33.3
38.369.5
Ø 20
Ø 12
M8
64
69.8
2.5
7 x 45°
