4.7.10 Wiring the "Result 2" Switching Output in the CDB620-001 Connection Module
6
1
10
5
11
15
PNP switching against the supply voltage V
S
(default setting: Good Read, 100 ms,
logic: not inverted [active high])
– Short-circuit proof + temperature protected
– Galvanically not separated from V
S
0 V ≤ V
out
≤ V
S
Guaranteed:
(V
S
− 1.5 V) ≤ V
out
≤ V
S
with I
out
≤ 100 mA
Switching
behavior
Features
Electrical
values
CLV61x
CDB620
U
IN
* = DC 10 V to 30 V
Load (e.g. PLC)
D-Sub HD plug,
15-pin
13
5
.
.
.
21Res 2
22
GND
5Shield
U
IN
*V
S
GND
Quenching circuit:
Install an anti-surge
diode directly at the
load!
For inductive load:
V
out
Result 2
GND
1
Ratings for "Result 2" switching output
