3.2.2 Product features and functions (overview)
Table 3: Overview of product features and functions of the device
Product feature/func‐
tion
Characteristic
Safety and ease of
use
•
Rugged, compact metal housing, CE marking
•
Laser Class 2, laser switches off if the output power is exceeded
•
Automatic self-test on system start
•
Diagnostic tools for system setup and (remote) system monitoring
•
Configurable output of reading diagnostic data in two reading
results formats
•
Operating data polling, in case of error, issue of error code if
required
•
Test string function (heartbeat) can be activated to signal that the
device is ready for operation
•
Password-protected configuration mode via SOPAS ET
•
Future-oriented by firmware update (FLASH PROM) via data inter‐
face
•
Future-oriented SOPAS ET configuration software
•
Low power consumption
•
Additional supply voltage range
•
Optional parameter cloning with external CMC600 parameter mem‐
ory module in the CDB/CDM connection module
Convenient operation/
configuration
•
Configuration via configuration software SOPAS ET (online/offline)
or commands
•
Configuration depending on the model via GSD configuration (via
CDF600-2xx or with Ethernet version device)
•
Status displays via LEDs
•
Auto setup of the optical reading properties
•
Profile programming with bar codes, generated and printed via
SOPAS ET
•
Two pushbuttons on the device to call up preset functions without
connecting a computer
•
Buzzer, which can be switched off, to confirm the device function
Read operation modes
•
Start/stop operation (one bar code bearing object per read pulse)
•
Tracking operation (CLV65x-x8300A)
Read cycle
•
Pulse sources for start: switching inputs, data interface (command),
auto pulse, free, CAN
•
Pulse sources for stop: read pulse source, switching inputs, data
interface (command), timer, condition
Bar code evaluation
•
All current 1D bar code types
•
Max. number of bar codes: 50 per reading interval
•
Separation of identical codes of the same code type using the read
angle
Data processing
•
Influencing the output of the reading data by event-dependent eval‐
uation conditions
•
Influencing the output string by filtering and output sorting
Data communication
•
Host interface: two data output formats can be configured, can be
switched to various physical interfaces, parallel operation possible
•
Aux interface: fixed data output format, can be switched to various
physical interfaces
3.2.3 Operating principle
The device consists of a laser scanner (laser diode and optics), an electronics unit with
integrated decoder and various data interfaces (type-dependent) to industrial bus sys‐
tems. The use of various focusing settings, resolutions, scan processes, bus systems,
mounting options and optics enables use in most industrial applications. Interfaces to
PRODUCT DESCRIPTION 3
8019588/129Z/2019-02-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x
17
Subject to change without notice
