Mounting the device is the same as mounting using mounting brackets, see "Mounting
device", page 29.
NOTICE
To prevent damage occurring during subsequent operation of the device, please
observe the following:
•
The ground traveled upon is in good condition (e.g. free from major unevenness
and potholes).
•
If the shock mount is mounted by the customer, we recommend wetting the
assembly screws with thread-locking fluid to prevent them from loosening. LOCI‐
TITE 268 is recommended.
•
Appropriate driving behavior when lowering the forks in forklift applications (e.g.
not driving with forks lowered, gentle lifting of the load).
•
We recommend using a soft-drop system.
NOTICE
Device damage due to lack of maintenance!
Mounting brackets with integrated vibration/shock absorption are subject to wear and
tear under heavier loads and therefore must be periodically checked and serviced. The
exchange intervals depend on the vibrations and shock effects (application specific).
5.7 Mounting external components
5.7.1 Mounting the connection module
If the device activation is carried out via a connection module, then this must be
mounted near to the device.
NOTE
If the PC with the SOPAS ET configuration software accesses the Aux interface
(RS-232; 57.6 kBd) of the device via the connection module, the connection module
should not be mounted more than 3 m of cable length away from the device.
1. Mount the connection module in the vicinity of the device.
2. Mount the connection module in such a way that the open module can be
accessed at all times.
NOTE
Detailed information on mounting and electrical installation can be found in the rele‐
vant operating instructions for the connection module.
5.7.2 Mount external read cycle sensor
If the device is triggered via an external read cycle sensor (photoelectric retro-reflective
sensor), then the sensor must be mounted in the vicinity of the device.
NOTE
A wide range of photoelectric sensors as well as accessories (brackets, connecting
cables) can be found at www.sick.com.
MOUNTING 5
8019588/129Z/2019-02-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x
37
Subject to change without notice
