SICK CLV63 Series User Manual

12 Technical data
NOTE
The relevant online data sheet for your product, including technical data, dimensional
drawing, and connection diagrams can be downloaded, saved, and printed from the
Internet:
•
www.sick.com/CLV63x
•
www.sick.com/CLV64x
•
www.sick.com/CLV65x
These operating instructions provides additional technical data if required.
12.1
Optics
CLV63x CLV64x CLV65x
Working range/
resolution
CLV630 Long
Range:
0.35 mm ...
1.0 mm
CLV631 Mid
Range:
0.25 mm ...
0.5 mm
CLV632 Short
Range:
0.2 mm ...
0.5 mm
CLV640 Standard
Density:
0.2 mm ...
1.0 mm
CLV642 High
Density:
0.15 mm ...
0.25 mm
CLV650 Standard
Density:
0.25 mm ...
1.0 mm
CLV651 Low Den‐
sity:
0.5 mm
Scanning method Line scanner, grid scanner
1)
, or line scanner with oscil‐
lating mirror
2)
.
Reading window
orientation
On the front or to the side (light emission at 105° rela‐
tive to the longitudinal axis of the device),
2)
.
Aperture angle ≤50°
Focus Fixed focus Dynamic focus
adjustment
Auto-focus/
dynamic focus
adjustment
Scanning fre‐
quency
400 Hz ... 1,200 Hz 600 Hz ...
1,000 Hz
Light source Laser diode, visible red light (λ =
655 nm)
Laser diode, visi‐
ble red light (λ =
658 nm)
Light spot Circular/oval (depending on type)
2)
. -
Reading distance Information on the reading distance, see "Reading field
diagrams", page 74.
Grid height, num‐
ber of lines, from
a distance
On the front 15 mm, 8, 200 mm -
On the side 15 mm, 8, 185 mm -
Oscillating mirror
functions
Fixed (adjustable position), oscillating (variable or fixed
amplitude), one-shot
Oscillation fre‐
quency
0.5 Hz ... 6.25 Hz
Angle of deflec‐
tion
‒20° ... 20°
MTBF 40,000 h
12 TECHNICAL DATA
70
O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x 8019588/129Z/2019-02-07 | SICK
Subject to change without notice
