12.4 Mechanics/electronics
CLV63x CLV64x CLV65x
Electrical connec‐
tion
Management: 1 x 15-pin D-Sub-HD male connector (0.9 mm)
1 x cable, open-ended, 3-wire (2 m) (with heating)
3)
12-pin Ethernet: 2 x M12 round connectors (1 x 12-pin male connector,
A-coding, 1 x 4-pin female connector, D-coding) on swivel
connector
1 x cable, open-ended, 3-wire (2 m) (with heating)
3)
17-pin Ethernet: 2 x M12 round connectors (1 x 12-pin male connector,
A-coding, 1 x 4-pin female connector, D-coding) with
swivel connector
3)
Ethernet 17-pin
IP69K
2 x M12 round connectors (1 x 17-
pin male connector, A-coding, 1 x 4-
pin female connector, D-coding)
3)
-
Supply voltage V
S
18 V DC ... 30 V DC
≤ 24 V DC, ± 10% (with heating)
3)
LPS or NEC Class 2, reverse polarity protected
Power consump‐
tion
1)
(devices
without heating)
Line or grid scan‐
ner: Typically 5 W
at DC 24 V ± 10%
Line or grid scan‐
ner: Typically
5.5 W at DC 24 V
± 10%
Line scanner:
Typically 8.5 W at
DC 18 ... 30 V
Line scanner with
oscillating mirror:
typically 9.5 W
Power consump‐
tion (devices with
heating)
Max. 40 W (max. 2.4 A)
Housing Aluminum die cast, stainless steel (unpainted) (IP69K)
Housing color Light blue (RAL 5012)
Reading window
material
Glass or polycarbonate pane
3)
.
Weight
2)
On the front Standard variant (cable): 320 g
Standard variant (cable) with heating
3)
: 520 g
Ethernet variant: 250 g
Ethernet variant with heating
3)
: 450 g
Ethernet IP69K variant
3)
: 890 g
On the side Standard variant (cable): 340 g
Standard variant (cable) with heating
3)
: 540 g
Ethernet variant: 270 g
Oscillating mirror Standard variant (cable): 420 g
Standard variant (cable) with heating
3)
: 620 g
Ethernet variant: 350 g
Ethernet variant with heating
3)
: 550 g
Ethernet IP69K variant
3)
: 1230 g
TECHNICAL DATA 12
8019588/129Z/2019-02-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x
73
Subject to change without notice
