CLV63x CLV64x CLV65x
Laser class Class 2 according to EN/IEC 60825-1: 2014
Identical laser class for issue EN/IEC 60825-1:2007
Complies with 21 CFR 1040.10 except for tolerances
according to Laser Notice no. 50, dated June 24, 2007.
Laser power
(maximum/aver‐
age)
3.2 mW/< 1.0 mW CLV650:
7.0 mW/
< 1.0 mW
CLV651:
4.5 mW/
< 1.0 mW
Laser pulse dura‐
tion
< 300 μs < 80 μs
Bar code print
contrast (PCS)
≥ 60%
Ambient light
immunity
2,000 lx, (on bar code)
1)
Grid height approx. 15 mm at a reading distance of 200 mm.
2)
Identifier see "Type code", page 13.
12.2 Performance
CLV63x CLV64x CLV65x
Bar code types Code 39, Code 128, Code 93, Codabar, GS1-128 / EAN 128, UPC/
GTIN/EAN, 2/5 Interleaved, Pharmacode, GS1 DataBar, Telepen, MSI/
Plessey
Print ratio 2:1 ... 3:1
No. of codes per scan 1 ... 20 (standard decoder)
1 ... 6 (SMART decoder)
No. of codes per read‐
ing interval
1)
1 ... 50 (auto-discriminating)
No. of characters per
code (reading interval)
Max. 50 characters (max. 5000 characters across all bar codes per
reading gate, 500 characters for multiplexer function (CAN))
Number of multiple
readings
1 ... 99
1)
Reading interval: The time window generated internally by the reading cycle for code detection and evalu‐
ation
12.3 Interfaces
CLV63x CLV64x CLV65x
Serial (RS-232,
RS-422/-485)
Function: Host, AUX (RS-232 only)
Data transmis‐
sion rate:
2.4 kBd ... 115.2 kBd, AUX: 57.6 kBd (RS-232)
Ethernet
Ethernet version
only
Function: Host, AUX
Data transmis‐
sion rate:
10/100 Mbit/s, half/full duplex
Protocol: TCP/IP, EtherNet/IP
TECHNICAL DATA 12
8019588/129Z/2019-02-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x
71
Subject to change without notice
