300
(11.81)
180
(7.09)
240
(9.45)
120
(4.72)
60
(2.36)
0
Reading distance in mm (inch) 2
Resolution 3
a: 0.20 mm (7.9 mil)
c: 0.50 mm (19.7 mil)
b: 0.35 mm (13.8 mil)
–80
(–3.15)
–40
(–1.57)
–120
(–4.72)
40
(1.57)
120
(4.72)
80
(3.15)
0
Reading field height in mm (inch) 1
a
b
c
Figure 56: Reading field diagram CLV632, short range, reading window on side
1
Reading field height in mm (inch)
2
Reading distance in mm (inch)
3
Solution
300
(11.81)
180
(7.09)
240
(9.45)
120
(4.72)
60
(2.36)
0
Reading distance in mm (inch) 2
Resolution 3
a: 0.20 mm (7.9 mil)
c: 0.50 mm (19.7 mil)
b: 0.35 mm (13.8 mil)
–80
(–3.15)
–40
(–1.57)
–120
(–4.72)
40
(1.57)
120
(4.72)
80
(3.15)
0
Reading field height in mm (inch) 1
a
b
c
Figure 57: Reading field diagram CLV632, short range, oscillating mirror, reading window on side
1
Reading field height in mm (inch)
2
Reading distance in mm (inch)
3
Solution
TECHNICAL DATA 12
8019588/129Z/2019-02-07 | SICK O P E R A T I N G I N S T R U C T I O N S | CLV63x, CLV64x, CLV65x
83
Subject to change without notice
