7.2 Overview
Prerequisites
•
Mount
ing has been completed correctly.
•
Electrical installation has been completed correctly.
Further topics
•
"Project planning", page 14
•
"Mounting", page 27
•
"Electrical installation", page 36
7.3 Switching on
Overview
Af
ter switching on, the sender and receiver initialize. All light emitting diodes of the
sender and receiver briefly light up. After initialization, the receiver displays the align‐
ment quality using four blue light emitting diodes. Once the safety light beam curtain is
aligned (OSSD LED: green), the alignment display switches off after a certain period of
time, and only the PWR LED of the sender and the OSSD LED of the receiver continue
to light up.
In the event of a fault, the red fault LED flashes on the respective device. A red fault
LED in combination with the blue LEDs shows the cause of the fault on the side of the
receiver.
Further topics
•
"T
roubleshooting", page 49
7.4 Sender and receiver alignment
Overview
Af
ter mounting and electrical installation, the sender and receiver must be aligned with
each other.
Important information
DANGER
D
angerous state of the machine
b
Make sure that the dangerous state of the machine is (and remains) switched off
during the alignment process.
b
Make sure that the outputs of the multiple light beam safety device do not affect
the machine during the alignment process.
Further topics
•
"Ali
gnment with the QuickFix bracket", page 42
•
"Alignment with the FlexFix bracket or with the upgrade bracket", page 43
•
"Indication of the alignment quality", page 44
•
"Diagnostic LEDs", page 49
7 C
OMMISSIONING
40
O P E R A T I N G I N S T R U C T I O N S | deTem4 Core 8020453/14Q7/2020-04-27 | SICK
Subject to change without notice
