*) Exception for protective field height 300 mm
H
≤ L
/4*
L
≤ L /4
± 15°
Figure 24: FlexFix bracket: Vertical adjustment / rotation
7.4.5 Indication of the alignment quality
Important information
NOTE
Once t
hree blue alignment quality light emitting diodes light up, alignment is good and
availability is stable.
Please note that body parts or objects between the sender and receiver (e.g., hand,
tool, AR60 optional laser alignment aid) will impair the function of the alignment quality
LEDs. Remove all objects from this area to allow the alignment quality to be assessed.
Indication of the alignment quality
T
able 6: Indication of the alignment quality
LEDs Meaning
Alignment quality light emitting
diode
s
OSSD
1 2 3 4
o o o o O R
ed
Alignment is insufficient or a light beam is
int
errupted at least partially. The receiver
cannot synchronize with the sender.
O Blue o o o O R
ed
Alignment is insufficient or a light beam is
int
errupted at least partially.
O Blue O Blue o o O R
ed
Alignment is insufficient or a light beam is
int
errupted at least partially.
7 COMMISSIONING
44
O P E R A T I N G I N S T R U C T I O N S | deTem4 Core 8020453/14Q7/2020-04-27 | SICK
Subject to change without notice
