SICK deTem4 Core - Table of Weights; Weight of Sender and Receiver

E.g., wire cross-section 0.34 mm²,
copper c
able
15 m
E.g., wire cross-section 0.5 mm²,
copper cable
30 m
Ambient operating temperature
2) 3)
–30 °C … +55 °C
Air humidity (non-condensing) 15 % … 95 %
Storage temperature –30 °C … +70 °C
Housing cross-section 31 mm × 34 mm, plus bracket, see "Dimensional dr
aw‐
ings", page 56
Weight Dependent on the number of beams, see "Table of
weights", page 55
Vibration resistance
4)
5 g, 10 Hz … 55 Hz (IEC 60068-2-6)
Shock resistance
5)
10 g, 16 ms (IEC 60068-2-27)
1)
Maximum permissible conductor resistances must be observed.
2)
The temperature difference between sender and receiver must not exceed 25 K.
3)
The cable belonging to the device incl. the associated connection plug must not be flexibly mounted
under -25°C
.
4)
Test conditions per axis: 1 octave/minute, amplitude: 0.35 mm, 20 sweeps.
5)
Test conditions per axis: 1,000 shocks.
12.2 Table of weights
Table 13: Weight of sender and receiver
Number of beams Weight in g
1)
s S
ender r Receiver
2 560 560
3 800 800
4 880 880
1)
Tolerance: ± 50 g
TECHNICAL DATA 12
