OSSD LED ERR-LED Alignment quality LEDs Possible cause Rectification
1 2 3 4
O R
ed Ö Red o o Ö Blue o
The receiver has recog‐
ni
zed beams from sev‐
eral senders.
Check the distance to
senders of the same
type. Make sure that
beams from another
sender cannot hit the
receiver, see "Protec‐
tion against interfer‐
ence from systems in
close proximity to each
other", page 19. Switch
the voltage supply off
and then on again.
O R
ed Ö Red o o o Ö Blue
A fault or unexpected
s
tatus was identified on
the OSSDs of the sys‐
tem connection
(e.g., overvoltage,
short-circuit to HIGH or
short-circuit to LOW,
cross-circuit, permissi‐
ble load capacity
exceeded)
Check the system
wiring for a fault. Make
sure that the OSSDs
have been wired cor‐
rectly, see "Integrating
into the electrical con‐
trol", page 19. Switch
the voltage supply off
and then on again. If
the fault persists,
replace the defective
components, see
"Ordering information",
page 57.
o LED of
f. Ö LED flashes. O LED illuminates.
