Name Description
Measuring Direction Select measuring direction for the distance.
Options
•
Negative direction [-]
•
Positive direction [+]
Factory setting
•
Positive direction [+]
Error Rejection Select time for maximum error suppression. If no measurement is possi‐
ble due to an error (e.g. brief light beam interruption), measured value
are extrapolated until no later than when the set error suppression time
expires. During this time, a WrnPlb plausibility warning is output. If no
measurement is possible after expiration of the error suppression time,
measured value 0, plausibility error ErrPlb and possibly other errors (e.g.
level error ErrLvl) are output.
Options
•
200 ms: Plausibility error is reported when the error is indicated for
longer than 200 ms.
•
50 ms: Plausibility error is reported when the error is indicated for
longer than 50 ms.
•
Off: The plausibility error is reported when the error is indicated for
longer than 5 ms.
Factory setting
•
200 [ms]
Heating threshold
[degC]
NOTE
Only for DL100-xxHxxxxx variants with heating
Select the ambient temperature below which the heater should switch
on. The hysteresis is fixed at 3 K. Increasing the temperature set at the
factory can reduce the formation of condensation in some cases.
Options
•
–10 … +40 °C
Factory setting
•
–10 °C
Frequency Mode
NOTE
Only for DL100-xxxBxxxx variants with frequency changeover
Set the laser transmission frequencies. If the minimum distance between
the optical axes cannot be maintained when mounting several distance
sensors, mutual interference is prevented by setting different frequencies
(mode 0 ... mode 2). No minimum distance is required for this purpose
see "Placement of multiple distance sensors", page 21.
Mode 0 corresponds to the laser transmission frequency of the variant
without switchable frequency (DL100-xxxAxxxx). Mode 3 is reserved for
later use.
Options
•
Mode 0
•
Mode 1
•
Mode 2
•
Mode 3 (reserved)
Factory setting
•
Mode 0
PROFINET IO INTERFACE 10
