SICK DME4000 User Manual

Operating Instructions Chapter 6
DME4000
8014584/ZN33/2017-07 © SICK AG • Germany • Subject to change without notice 101
Specifications
6.5 Specifications DME4000-2xx
DME4000-
211
212
213
214
215
217
219
Part no.
10297909
1029791
1029798
1029802
1029803
1029806
1042839
Measurement range
0.15 … 130 mm
Accuracy
± 5 mm
Reproducibility
1)
2 mm
Measurement value output
1 ms
2 ms
2 ms
2 ms
2 ms
2 ms
4 ms
Resolution (adjustable)
0.05 … 5 mm
Temperature drift (type)
0.1 mm/K
Temperature influence
1 ppm/K
Air pressure influence
0.3 ppm/hPa
Initialization time
500 ms
900 ms
500 ms
Max. movement speed
10 m/s
Supply voltage V
S
2)
18 … 30 V DC
Residual ripple
3)
5 V
PP
Current consumption (without
heating)
< 250 mA at 24 V DC
Optical transmitter
Laser diode (red light)
Laser class
2 (EN 60825-1/C.D.R.H.)
Operating life (at 25 °C)
MTTF 50,000 h
Light spot diameter/distance
max. 240 mm/130 m
Switching outputs MF1, MF2
B (push/pull)
Output (MF1/MF2)
HIGH: V
S
< 3 V; LOW < 2 V
Input (MF1)
4)
HIGH: > 12 V; LOW < 3 V
Output current
5)
100 mA (short-circuit protected, overload-protected)
Interfaces
SSI
PROFIBUS
12 MBd
RS 422
DeviceNet 500 kBd
Hiperface
CANopen
Ambient operating temperature
–10 … +55 °C
Storage temperature
–25 … +75 °C
DME4000 heating
221
222
223
224
Not
available
227
Part no.
1029794
1029795
1029799
1029805
1029804
Ambient operating temperature
–40 … +55 °C
Current consumption
(with heating)
< 1000 mA
Enclosure rating
IP 65
Electric protection class
VDE class 2 (rated voltage 32 V)
EMC
EN 61000-6-2, EN 55011: class B
Mechanical load
Shock: EN 600 68-2-27/-2-29, Sinus: EN 600 68-2-6, noise: EN 600 68-2-64
Weight
Approx. 1650 g
1)
Statistical error, constant ambient conditions, minimum switch-on time 10 min
2)
Reverse-polarity protected
3)
May not exceed or fall short of V
S
tolerances
4)
Not reverse-polarity protected
5)
Max. 100 nF/20 mH
