Operating Instructions Chapter 4
DME4000
8014584/ZN33/2017-07 © SICK AG • Germany • Subject to change without notice 87
Operation Startup
Illustration 4.15 –No “pigtails”; connect the shield at a short distance and over the
complete area; ground BOTH sides
Illustration 4.16 – Shield connection for plastic housing
4.2.2 PROFIBUS Terminator Connection
Illustration 4.17 –PROFIBUS Terminator Connection (refer to the accessories in
Chapter 6.3.2 “Plugs/Cables“)
Terminator
