Illustration 6.7 – DME4000-xx5 Connection Diagram (DeviceNet M12 plug)
Illustration 6.8 – DME4000-xx7 Connection Diagram (Hiperface M12 plug)
Illustration 6.9 – DME4000-xx9 Connection Diagram (CANopen M12 plug)
6.3 Accessories
6.3.1 Reflectors
Reflector 0,3 x 0,3 m
2
Diamond Grade, mounted
Reflector 0,6 x 0,6 m
2
Diamond Grade, mounted
Typ: PL 240 DG Part no.: 1017910 Typ: PL 560 DG Part no.: 1016806
