Operating Instructions Chapter 6
DME4000
8014584/ZN33/2017-07 © SICK AG • Germany • Subject to change without notice 93
Reflector 1 x 1 m
2
Diamond Grade, mounted
Typ: PL 880 DG Part no.: 1018975
Reflector 0.3 x 0.3 m² Diamond Grade, regulated heating AC
230 V/200 W
Reflector 0.6 x 0.6 m² Diamond Grade, regulated heating AC
230 V/900 W
Typ: PL 240 DG-H Part no.: 1022926 Typ: PL 560 DG-H Part no.: 1023888
Diamond Grade reflective tape, size made-to-order
Diamond Grade reflective tape, sheet 749 x 914 mm
2
Typ: REF-DG-K Part no.: 4019634 Typ: REF-DG Part no.: 5304334
6.3.2 Plugs/Cables
PROFIBUS, SSI and RS 422
M16 cable receptacle, 8-pin, straight
M16 cable receptacle, 8-pin, angled
