Specifications
M16 cable receptacle, 8-pin, straight, 5 m/50 m
M16 cable receptacle, 8-pin, straight, 10 m
Typ: DOL-1608-G05MA
Part no.: 2026742
Typ: DOL-1608-G10MA
Part no.: 2027193
Typ: DOL-1608-G50MA
Part no.: 6032903
M16 cable receptacle, 8-pin, angled, 5 m M16 cable receptacle, 8-pin, angled, 10 m
Typ: DOL-1608-W05MA
Part no.: 2026743
Typ: DOL-1608-W10MA
Part no.: 2027194
Wire 2 x 0.5 mm², 6 x 0.25 mm²,
stranded in pairs, shielded
Specifications
Typ: LTG-2308-MW
Part no.: 6026292
Temperature range
Variable –5 ... +70 °C
Not variable –40 ... +80 °C
Sheathing
PUR grey
Shield
Tined cupper net
Connector view
Connector view
