SICK DME4000 User Manual

Operating Instructions Chapter 9
DME4000
8014584/ZN33/2017-07 © SICK AG • Germany • Subject to change without notice 111
Appendix
Octet
Active (1)
Not active (0)
Octet 1 … 6
DP standard diagnosis
Octet 7
Diagnostic Header
Octet 8
Alarms
Bit 0
Measurement error
Bit 3
Pre-failure message
Bit 4
Sensor error
Bit 1, 2, 5, 6,
7
Not assigned
Octet 9
Operating
Status
Bit 1
Class 2
Class 1
Bit 6
Extended diagnostics
Normal diagnostics
Bit 7
Preset mode: offset parameter is ignored
Offset parameter is
used
Bit 0, 2, 3, 4, 5
Not assigned
Octet 10
Encoder Type 7
Octet 11 … 14
Measuring step (linear)
Octet 15 … 16
Not assigned
Octet 17
Alarms
Bit 0
Sensor error
Bit 1
Internal sensor temperature too high/too
low
Bit 2
Plausibility (see PLB indicator)
Octet 17
Alarms
Bit 3
Bus communication interference
Bit 4, 5, 6, 7
Not assigned
Octet 18
Supported alarms in Octet 17
Octet 19
Supported alarms in Octet 8
Octet 20
Warnings
Bit 0
Laser pre-failure message
Bit 1 ... 7
Not used
Octet 21
Warnings
Bit 1
Internal sensor temperature
Bit 2
Soiling
Bit 0, 3 ... 7
Not used
Octet 22
Supported warnings in Octet 20
Octet 23
Supported warnings in Octet 21
Octet 24 … 25
Profile version
Octet 26 … 27
Software version
Octet 28 … 31
Operating time (unit 0.1 h)
Octet 32 … 35
Offset in units corresponding to resolution
Octet 36 … 47
Not used
Octet 48 … 57
Series number (2 blanks + 8 valid ASCII characters)
Octet 58 … 59
Reserved
Octet 60
Temperature (2
nd
complement)
Octet 61
Measurement channel level (2
nd
complement)
Octet 62
MF status
Octet 63
Bit 7
Laser on
Laser off
Bit 0 ... 6
Not used
