11.2 Mechanics/electronics
Device type GLS621
Connection type 1 male connector, M12, 17-pin, A-coded
1)
1 female connector, M12, 4-pin, D-coded
1)
1 female connector, USB, 5-pin, Micro-B type
1 microSD card slot
Supply voltage V
S
12 V AC ... 24 V DC, ± 20%
Voltage source in accordance with ES1 and PS2 (EN 62368-1) or
SELV and LPS (EN 60950-1).
Power consumption Operation: 4 W typical
2)
Maximum 22 W with typical loading of the 4 digital outputs with
100 mA each and 28.8 V DC supply voltage.
Current consumption Max. 0.8 A with DC 28.8 V
Housing material Die cast aluminum, plastic
Housing color Light blue (RAL 5012), black
Viewing window material Plastic (PMMA), 2 mm thick, with scratch-proof coating
Hinged cover (rear of
device)
Plastic. Hinge-open cover
3)
for temporary access to USB interface
and memory card slot. 2 x fixing screws TX6, captive.
Enclosure rating IP65 (EN 60529, EN 60529 / A2)
Protection class III
Electrical safety EN 62368-1
Weight 170 g
Dimensions (L x W x H) 88.5 mm x 43 mm x 35.6 mm
1)
On swivel connector.
2)
For digital outputs without load.
3)
When the flap is open, the device no longer conforms with the specified enclosure rating.
4)
see "Device view", page 14. Swivel connector protrudes by 17.8 mm.
11.3 Performance
Device type GLS621
Image sensor resolution 1.3 Mpx (1,280 px x 1,024 px)
Image sensor type (color) CMOS matrix sensor, monochrome (black/white)
Image recording rate 1.3 Mpx: 50 Hz
Readable code structures 2D
2D code types Data Matrix ECC200, QR code
Code qualification On the basis of ISO/IEC 16022, ISO/IEC 15415, ISO/IEC 15416,
ISO/IEC 18004
Evaluation time ≥ 100 μs
1)
The overspeed is dependent on reading distance, alignment and the 2D code used, see "Typical refer‐
ence values during operation", page 56.
11 TECHNICAL DATA
52
O P E R A T I N G I N S T R U C T I O N S | GLS621 8024289/19E9/2020-10-21 | SICK
Subject to change without notice
