11.4 Interfaces
Device type GLS621
Ethernet Protocol:
•
TCP/IP
•
EtherNet/IP
Function
•
Host (data output of the read result)
•
AUX (Service)
•
OPC DA Server
•
FTP (image transfer)
Data transmission rate: 10/100 Mbit/s
Services: DHCP, NTP, HTTP, mDNS, DNS-SD. DNS and HTTPS
MAC address (device-specific), see type label
PROFINET Function: PROFINET single port
Data transmission rate: 10/100 Mbit/s
Serial RS-232 / RS-422 Function: host (data output of the read result)
Data transmission rate: 0.3 kBd ... 115.2 kBd
Serial RS-232 Function: AUX (service)
Data transmission rate: 57.6 kBd
CAN Function: SICK CAN Sensor Network CSN (Master/Slave, Multi‐
plexer/Server)
Protocol:
•
CSN (SICK CAN sensor network)
•
A connection in a CANopen-based environment is possible. For
additional support, please contact SICK customer service.
Data transmission rate: 20 kBit/s ... 1 MBit/s
Bus length: maximum 30 m
USB 2.0
2)
Function: AUX (service)
Digital outputs Type: 4 physical, switching (“Result1”, “Result2”, “Result3”,
“Result4”)
V
out
3)
= V
S
4)
– 1.5 V, I
out
5)
≤ 100 mA (typical)
Short-circuit protected, not electrically isolated from the supply
voltage
Optical indicators 5 status LEDs on the top of the device
10 bar graph LEDs (blue) on the top of the device
1 feedback LED (green) as light area on code
1 status LED (status indicator for the memory card), under hinged
cover
Acoustic indicator Beeper (buzzer), can be deactivated
6)
Function for event signaling adjustable
6)
Configuration tools (para‐
meterization)
SOPAS ET configuration software, CoLa commands (telegrams),
fieldbus controller (PLC) with additional support by SICK function
blocks, function buttons
Memory card MicroSD memory card (flash card), optional, max. 32 GB
Data storage and retrieval image and data storage via microSD memory card and external
FTP
Maximum encoder fre‐
quency
300 Hz
External illumination con‐
trol
Via digital output (max. 24 V trigger)
1)
For example: Configuration, diagnosis, transponder access or display of the read result.
