2)
Data interface only for temporary use (service).
3)
Output voltage.
4)
Supply voltage.
5)
Output current.
6)
e.g. with SOPAS ET configuration software.
11.5 Ambient data
Device type GLS621
Electromagnetic compati‐
bility (EMC)
Radiated emission: EN 61000-6-4: 2007-01 + A1: 2011-03
Immunity: EN 61000-6-2: 2005-08
Vibration resistance EN 60068-2-6:2008-02
Shock resistance EN 60068-2-27:2009-05
Ambient operating temper‐
ature
1)
•
0 °C ... +40 °C
•
0 °C ... +50 °C, if the device is mounted on a mounting angle
to dissipate the heat.
Storage temperature –20 °C ... +70 C
Permissible relative
humidity
0% ... 90%, non-condensing
Ambient light immunity 2,000 lx on code
1)
Notes regarding adequate dissipation of heat loss, see "Installation requirements", page 24.
11 TECHNICAL DATA
54
O P E R A T I N G I N S T R U C T I O N S | GLS621 8024289/19E9/2020-10-21 | SICK
Subject to change without notice
