CommentBinaryRangeAttributeValue tagContainer tag
Name attribute required if
more than one Edge Pixel
Counter exist
any stringnameEDGE_
PIXEL_
COUNTER
Number of found edge pixels,
expressed in pixels of the in-
UDINTPIXELS
spection region area. The No.
of edge pixels interval in the Tools
tab is specified as number of
pixels within the inspection re-
gion. If the located object is
scaled, the number of pixels is
adjusted to be the number of
matching pixels that should
have been found if the located
object had the same size as
the reference object.
0=fail, 1=pass, 2=Outside im-
age
USINT{0, 1, 2}DECISION
Name attribute required if
more than one Pixel Counter
exist
any stringnamePIXEL_
COUNTER
Number of found pixels, ex-
pressed in pixels of the inspec-
UDINTPIXELS
tion region area. The No. of
pixels in range interval in the
Tools tab is specified as num-
ber of pixels within the inspec-
tion region. If the located ob-
ject is scaled, the number of
pixels is adjusted to be the
number of matching pixels that
should have been found if the
located object had the same
size as the reference object.
0=not found, 1=found, 2=Out-
side image
USINT{0, 1, 2}DECISION
Name attribute required if
more than one Pattern inspec-
tion exists
any stringnamePATTERN
X position of the reference
point. Note that this can be
REALcoordUnitX
outside the image and there-
fore negative. In “pixels” or
“mm” depending on attribute
“coordUnit” or configured value
in the Ethernet Result output dia-
log.
Y position of the reference
point. Note that this can be
REALcoordUnitY
outside the image and there-
fore negative. In “pixels” or
“mm” depending on attribute
“coordUnit” or configured value
41
©SICK AG • Advanced Industrial Sensors • www.sick.com • All rights reserved
Subject to change without notice
8015726/2013-11
Appendix
Result output formatting
Reference Manual
Inspector PIM
