g
The angle of the edge relative to the region.
h
The INTERNAL_ANGLE is the angle of a feature, i.e. the relation of the two edges of the feature.
Note
When a tool is related to the object locator and the object locator is not found in the live image
the presented results for the related tools are undefined.
A.3.1 General tags
Table A.2 Generic output string tags
CommentBinaryRangeAttrib-
ute
Value tag
UINTMESSAGE_SIZE • Binary format: The size of the message
in bytes
• ASCII format: The number of characters
in the message
Analyzed image's number (Resets at
power-up or device reset)
UDINTIMAGE_NUMBER
0=Not located, 1=Detail failed, 2=All
passed 3=Not located and detail failed
a
USINT[0, 3]IMAGE_DECISION
Reference object index
b
USINT[0, 31]REF_OBJECT
Used to send single control charactersIGNORED[0, 255]valueASCII
Same
as
<ASCII
value="32"/>
IGNORED
SP
A
CE
Same
as
<ASCII
value="9"/>
IGNORED
T
AB
Left angular bracket, "<". Useful when
generating XML-formatted output.
IGNOREDLAB
Right angular bracket, ">". Useful when
generating XML-formatted output.
IGNOREDRAB
8015726/2013-11
©SICK AG • Advanced Industrial Sensors • www.sick.com • All rights reserved
Subject to change without notice
48
Reference Manual
Result output formatting
Appendix
Inspector PIM
