CommentBinaryRangeAttributeValue tagContainer tag
a clockwise rotation and a
negative value is a counter
clockwise rotation.
g
The angle of the single edge in
degrees or radians depending
on attribute “unit” or con-
figured value in the Ethernet
Result output dialog.
Only applicable for Feature type
Dark or Bright. The edge's or
REAL[0, 180]INTERN-
AL_ANGLE
feature's angle in the search
region.
h
The angle of the feature in de-
grees or radians depending on
attribute “unit” or configured
value in the Ethernet Result out-
put dialog.
Only applicable for Feature type
Dark or Bright.
REALWIDTH
If the chosen Edge counter is
rectangular the value shows
the width “pixels” or “mm” de-
pending on attribute “co-
ordUnit” or configured value in
the Ethernet Result output dialog.
If the chosen Edge counter is
circular the value is the width
in degrees or radians depend-
ing on attribute “unit” or con-
figured value in the Ethernet
Result output dialog.
Only applicable for Feature type
Single edge. The chosen edge's
USINT[3, 4]POLARITY
polarity in the search direction:
3 = dark to bright, 4 = bright to
dark
a
This tag must be used inside the <POLYGON> container
b
Only available for Ethernet Raw.
c
For EtherNet/IP the position is represented as an INT value. Use the scale attribute to get more decimals
d
This tag must be used inside the <BLOB> container. The value are given for each Blob ROI (not for each found
blob)
e
This tag concerns the whole tool, i.e. not specific to the feature/edge chosen by the index
f
Red arrow points out the midpoint for the Edge count tool
47
©SICK AG • Advanced Industrial Sensors • www.sick.com • All rights reserved
Subject to change without notice
8015726/2013-11
Appendix
Result output formatting
Reference Manual
Inspector PIM
